NAMES OF PARTS (Fig. 1 – Fig. 14)
1
Rechargeable battery
!
Shift knob
2
Latch
@
Trigger switch
3
Handle
#
Sleeve
4
Pilot lamp
$
Push button
5
Triangle mark
%
Hook (sold separately)
6
Mode-switching dial
^
Screw
7
Screw-tightening
mark
&
Groove
8
Drill mark
*
Display panel
9
Hammer mark
(
Remaining battery
indicator switch
0
Clutch dial
)
Remaining battery
indicator lamp
SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
DS12DA: Cordless Driver Drill
DV12DA: Cordless Combi Drill
To reduce the risk of injury, user must read
instruction manual.
Only for EU countries
Do not dispose of electric tools together with
household waste material!
In observance of European Directive 2012/19/
EU on waste electrical and electronic equipment
and its implementation in accordance with
national law, electric tools that have reached
the end of their life must be collected separately
and returned to an environmentally compatible
recycling facility.
Direct current
V Rated voltage
n
0
No-load speed
min
-1
Oscillation per minute
Bpm Impact rate
Ls Low speed
Hs High speed
Brick
Wood
Metal
Machine screw
Wood screw
Drill chuck capacity
kg
Weight*
(According to EPTA-Procedure 01/2014)
Screw – Tightening
Drilling
Impact drilling
Switching ON
Switching OFF
Disconnect the battery
Change rotation speed - High speed
Change rotation speed - Low speed
Clockwise rotation
Counterclockwise rotation
* Depending on attached battery. The heaviest weight is
measured with BSL1240M (sold separately).
Battery
Lights ;
The battery remaining power is over 75%
Lights ;
The battery remaining power is 50% – 75%.
Lights ;
The battery remaining power is 25% – 50%.
Lights ;
The battery remaining power is less than 25%
Blinks ;
The battery remaining power is nearly empty.
Recharge the battery soonest possible.
Blinks ;
Output suspended due to high temperature.
Remove the battery from the tool and allow it to
fully cool down.
Blinks ;
Output suspended due to failure or malfunction.
The problem may be the battery so please
contact your dealer.
NOTE
To prevent the battery power consumption caused by
forgetting to turn off the LED light, the light goes off
automatically in about 3 seconds.
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package contains the
accessories listed on page 30.
Standard accessories are subject to change without notice.
