Dreame V10 Plus White (VFW5) [10/81] Care maintenance

13 14

Note: To prevent injury from accidentally turning on the vacuum, make sure the Soft Roller

Nozzle or Mini-Motorized Nozzle is detached from the vacuum before removing the head.

The Mini-Motorized Nozzle and Soft Roller Nozzle contain electrical components, and the

Soft Roller Nozzle head also contains bearings. Do not wash these parts with water. Be

careful of sharp objects when removing debris caught in the heads of Soft Roller Nozzle

and Mini-Motorized Nozzle.

1. Push the brushbar head release button in the direction of the arrow until the cover of the

brushbar head pops to open, then remove the brushbar head by lifting it in the direction

indicated.

2. After you have ﬁnished cleaning the Soft Roller Nozzle , reinstall it by following the

disassembly steps in reverse.

Care & Maintenance

Cleaning the Soft Roller Nozzle and Mini-Motorized Nozzle

Cleaning the Soft Roller Nozzle

Care & Maintenance

2. Rinse the ﬁlter and foam pad with water. To thoroughly remove all dust caught in the

ﬁlter, rotate the ﬁlter by 360 degrees while rinsing. Lightly tap the ﬁlter against a sink

several times to remove any excess debris.Keep the ﬁlter in a well-ventilated and cool

place to fully dry.

Note: Fully dry the ﬁlter (at least 24 hours) before reinstalling it.

Cleaning the Filter Assembly

111

210

24 hrs

1. Place the vacuum securely on a ﬂat surface, then turn the ﬁlter assembly cover in the

direction indicated and remove the ﬁlter assembly.

Note: Remove the built-in foam pad before cleaning the ﬁlter assembly. Rinse the ﬁlter and

foam pad with water.
