Troubleshooting Specifications
If the vacuum is not working properly, please refer to the troubleshooting table below.
Error Possible Cause Solution
Vacuum does
not work
Vacuum is out of battery or low
on power.
Fully charge the vacuum, then
resume use.
Overheat protection mode
triggered by a blockage.
Wait until the vacuum cools down,
then reactivate it.
Suction opening or airway
passage is blocked.
Clear any blockages from suction
opening or airway passage.
Weak suction force
Dust compartment is full
and/or filter assembly is
clogged.
Empty the dust compartment and
clean the filter assembly.
Attachment is blocked.
Clear any blockages in the
attachment.
Motor makes a
strange noise
Main suction opening or
extension rod is blocked.
Clear any blockages in main suction
opening or extension rod.
Charges slowly
Battery temperature is too low
or too high.
Wait until the battery's temperature
normalizes, then resume use.
The first indicator
is red after turning
on the vacuum
Battery is damaged.
Please contact the after-sales service
department for maintenance.
The first indicator
blinks red after
turning on the
vacuum.
Power adapter is incompatible.
Only use the original power adapter
to charge the vacuum.
Battery indicator
does not light up
while charging
The adapter is not connected
to the vacuum.
Make sure the power adapter is
plugged in properly.
The battery is fully charged and
went into sleep mode.
Can be used normally.
If the problem persists after
ruling out the above two
possibilities.
Please contact the after-sales service
department for maintenance.
17 18
Model
Model
Model
Model
YLS0241u-x300080
(u=A or B，x=E or U )
30 V 0.8 A
100‒240 V~50/60 Hz
0.8 MAX
Average Active
Efficiency
86.98%
80.67 %
0.08 W
Efficiency at
Low Load (10%)
No-load Power
Consumption
Input
Output
Charging Time
DM001
DM002
Rated Voltage
Rated Voltage
Rated Voltage
Rated Capacity 2500 mAh
Charging Voltage
Rated Power
Rated Power
Rated Power
450 W
40 W
20 W
Approx. 3.5 hoursVFW5
30 V
Vacuum Cleaner
Soft Roller Nozzle
Mini-Motorized Nozzle
Power Adapter
25.2 V
25.2 V
Model DM004
Rated VoltageRated Power 40 W
Carpet Roller
25.2 V
Model YLS0251B-E300080
30 V 0.8 A
100‒240 V~50/60 Hz
0.8 A
Average Active
Efficiency
88.53 %
78.66 %
0.09 W
Efficiency at
Low Load (10%)
No-load Power
Consumption
Input
Output
Power Adapter
25.2 V
