Planta FD-BIKE-005 (X-bike) [23/25] Страница 23

so that the front and rear axles of the main frame converge as close to each other as

possible, but without excessive pressure.

The movement of the simulator in the folded form is carried out according to the same

principle as in the unfolded one.

The PLANTA FD-BIKE-005 folding exercise bike must be stored in a clean, dry place.

To save space, it is advisable to fold the exercise bike between sessions. However, it

can be stored both folded and unfolded, which does not affect its service life.

Regularly check and tighten all parts of the exercise bike. To clean the exercise bike,

use a damp cloth and a small amount of mild detergent. After cleaning, leave the

simulator unfolded until the surface is completely dry and only then fold the simulator

for further storage (if necessary).

ATTENTION! To prevent damage to the monitor display, do not store the

machine near liquids or expose it to direct sunlight.

Installing and replacing batteries

Open the battery cover on the back of the monitor.

Install or replace 2 x 1.5V AAA batteries according to the diagram below:

Troubleshooting

The monitor's display has become dim or has stopped displaying readings.

џ Make sure the batteries are inserted into the monitor and the connecting cables

are connected correctly.

џ Replace Batteries - To replace batteries, refer to the Installing and Replacing

Batteries section of this manual.

Extraneous sounds / creaking appear during exercise

џ Make sure that all the connecting screws of the simulator are tightly tightened.

Tighten them if necessary.

џ If sounds are made by the pedals of the simulator, lubricate them at the base of

the cranks with special technical oil.
