5
ENGLISH
Battery charging
Before using the unit for the first time or after a long
period of inactivity, the battery (14) needs to be charged
for 4-5 hours.
A fully charged battery (14) provides 18 minutes of
continuous vacuum cleaner operation at maximal
power and about 30 minutes of operation at low
power level.
•
Insert the plug of the power supply unit connecting
cord into the battery socket of the vacuum cleaner
(14), plug the power supply unit into the socket (fig.
9), the operation/charging indicators (3) will light up,
the light indicators (3) will show the charging state of
the battery.
•
At the end of the charging cycle of the battery (14),
four indicators (3) will light up.
•
After the end of the charging cycle, insert the vacuum
cleaner in the wall-mounted holder (13) (fig. 10).
Notes:
–
Charge the battery (14) at the temperature from +5°C
to +35°C.
–
If you haven’t used the unit for a month or longer,
charge the battery (14) completely before using the
vacuum cleaner.
Attaching the extension pipe and attachments
•
Insert the extension pipe (5) into the air inlet of the
vacuum cleaner until the release button (4) clicks
(fig. 1 and 2).
•
Select the required attachment: motorized turbo
brush with LED illumination (7) or crevice nozzle (12)
and connect it to the extension pipe (5) (fig. 3).
Notes:
–
If necessary, you can attach the motorized turbo
brush (7) or the crevice nozzle (12) straight to the air
inlet of the vacuum cleaner, without using the exten-
sion pipe (5).
Motorized turbo brush with LED lighting (7)
Use the motorized turbo brush (7) for cleaning floors
and carpets with medium and low pile, the brush (7) is
perfect for removing pet hair from carpets. The roller
with bristles is brought to rotation by an electric motor
built in the brush, its bristles thoroughly comb out pet
hair and sweep motes out of the carpet pile.
Notes:
–
Do not use the motorized turbo brush (7) if the pile
length exceeds 15 mm.
–
Do not run the brush (7) over electric wires.
–
Switch the vacuum cleaner off right after cleaning
with the brush (7).
Crevice nozzle 2-in-1 (12)
The nozzle (12) is intended for cleaning radiators, chinks,
corners and spaces between cushions.
USING THE VACUUM CLEANER
Attention! Switch the vacuum cleaner on only with the
dust bin (9) and the filters (10, 11) installed in the dust
bin. Always check if the dust bin (9) is assembled and
installed properly.
•
Use the wall-mounted holder (13) for easy storing of
the vacuum cleaner.
•
During the operation or when carrying the vacuum
cleaner hold the unit by the handle.
•
Press the on/off button (1) to switch the vacuum
cleaner on, the vacuum cleaner will be switched on at
the low power level, and four indicators will light up on
the operation/charging indicator (3).
•
During the vacuum cleaner operation you can select
the vacuum cleaner operating modes by pressing the
button (2) consecutively. The vacuum cleaner has
two operation modes:
–
the operation time at the low power level is approx-
imately 30 minutes.
–
a charged battery (14) provides approximately
18 minutes of continuous vacuum cleaner opera-
tion at maximal power.
CLEANING AND MAINTENANCE
Attention! Provide that the dust bin (9), the mesh
filter (10) and the HEPA filter (11) are always clean,
because the overall performance of the vacuum cleaner
depends on it.
Remove garbage and dust from the dust bin (9) after
each usage of the vacuum cleaner and clean the dust bin
(9), the mesh filter (10) and the HEPA filter (11) regularly.
Cleaning the dust bin (9)
•
Remove the dust bin (9), (fig. 1). Open the lower lid
(8) (fig. 5). Wash the filter (11) and mesh filter (10)
with clean water (fig. 7 and 8). Air dry the filters (10
and 11). Assemble them after they are dry (fig. 6).
Place the filters (10 and 11) back into the dust bin (9).
Notes:
–
Do not use heating units, including the hairdryer, to
dry the removable parts.
–
Before assembling the dust bin (9) and installing it
to its place make sure that all removable parts are
clean and dry.
Cleaning the motorized turbo brush
with LED lighting (7)
Keep the brush (7) clean; as it becomes dirty, disas-
semble the brush (7) and clean the roller.
•
Remove the brush (7) from the extension pipe (5) by
pressing the release button (6).
•
Move the roller clamp of the rotating brush forward.
•
Take out the roller and remove threads and hairs
wound up around it.
•
Clean the inner and outer surface of the brush (7)
body from garbage and dust.
Assembling the motorized turbo brush
with LED lighting (7)
•
Insert the right part of the roller into the body.
•
Install the left part of the roller to its place. Push the
roller clamp of the rotating brush until bumping.
•
Make sure that the roller is fixed properly.
Vacuum Cleaner Body Cleaning
•
Wipe the vacuum cleaner body with a soft, slightly
damp cloth and then wipe it dry.
•
Do not immerse the vacuum cleaner body, brush
(7), rechargeable battery (14) and power supply
unit in water or any other liquid. Make sure that no
liquid gets inside the vacuum cleaner body and the
brush (7).
•
Do not use solvents or abrasives for cleaning the vac-
uum cleaner body and the removable parts.
