5
ENGLISH
• Install the blades (4) on the motor axis (8), match the
groove on the motor axis (8) with the clamping nut (5)
and tighten the nut (5) counterclockwise until bumping.
Make sure that the blades (4) are fixed properly.
• Match the front grid (2) and the rear grid (7), fix them
with the clamp ring (3) and tighten up the clamp ring (3)
by turning the fixing screw and the nut (1) tight.
• The fan is ready for operation.
USING THE FAN
• Before switching the fan on, make sure that the mains
voltage corresponds to the unit operating voltage.
• Make sure that the fan is switched off. To do this, set the
switch (11) to the position «0».
• Insert the power plug into the mains socket.
• Select the required blades (4) rotation speed by pressing
the operation mode switch (11) buttons:
«0» – fan is switched off;
«1» – low blades rotation speed;
«2» – medium blades rotation speed;
«3» – high blades rotation speed.
• Press the button (10) to switch horizontal rotation of the
motor unit on. To switch the rotation mode off, pull the
button (10) upwards.
• To switch the fan off, set the operation mode switch (11)
to the position «0».
• Remove the power plug from the mains socket.
MAINTENANCE AND CARE
• Before cleaning the fan switch it off by setting the opera-
tion mode switch (11) to the position «0» and disconnect
the power plug from the mains socket.
• Do not use abrasive cleaners and solvents to clean the
fan.
• Clean the motor unit (9) body with a slightly damp cloth
and then wipe it dry.
• To clean the blades (4), unscrew the screw (1) on the
ring (3), remove the ring (3), remove the front grid (2),
and then wipe the blades with a slightly damp cloth.
• Install the front grid (2) and the ring (3) back to its place.
• You may clean the fan grids with a vacuum cleaner using
a proper attachment.
• Do not immerse the motor unit (9) into water or any other
liquids. Make sure that no liquids get into the motor unit
body (9) to avoid its damage and prevent risk of elec-
tric shock.
STORAGE
• Unplug the fan and clean it.
• If necessary, disassemble the fan.
• Remove the front grid (2), to do this unscrew the screw (1)
on the ring (3), remove the ring (3) and the front grid (2),
unscrew the blades clamping nut (5) turning it counter-
clockwise, then remove the blades (4), unscrew the fas-
tening nut (6) of the rear grid (7) and remove the grid (7).
• Remove the fastening screw and remove the motor unit
(9) from the floor support.
• Unscrew the clamp (17) and remove the crosswise base
(16) from the floor support.
• Pack the fan into the original package and put it away
for storage in a dry cool place away from children and
disabled persons.
DELIVERY SET
Motor unit – 1 pc.
Front grid – 1 pc.
Blades – 1 pc.
Rear grid – 1 pc.
The floor base – 1 pc.
Base – 1 pc.
Flat washer – 1 pc.
Clamp – 1 pc.
Set of rivets for the floor support – 1 pc.
Set of fastening screws – 1 pc.
Manual – 1 pc.
Warranty certificate – 1 pc.
TECHNICAL SPECIFICATIONS
Power supply: 220-240 V ~ 50 Hz
Rated input power: 40 W
Blades diameter: 36 cm
RECYCLING
For environment protection do not throw out the unit and
the batteries (if included), do not discard the unit and the
batteries with usual household waste after the service life
expiration; apply to specialized centers for further recy-
cling.
The waste generated during the disposal of the unit is sub-
ject to mandatory collection and consequent disposal in the
prescribed manner.
For further information about recycling of this product apply
to a local municipal administration, a disposal service or to
the shop where you purchased this product.
The manufacturer preserves the right to change design,
structure and specifications not affecting general princi-
ples of the unit operation without a preliminary notification
due to which insignificant differences between the manual
and product may be observed. If the user reveals such dif-
ferences, please report them via e-mail info@coolfort.ru
for receipt of an updated manual.
Unit operating life is not less than 3 years
Guarantee
Details regarding guarantee conditions can be obtained
from the dealer from whom the appliance was purchased.
The bill of sale or receipt must be produced when making
any claim under the terms of this guarantee.
