Centek CT-8585 Smart [32/52] Set up the internet connection once again see restart or

Media Player application. Once in the application, find and open the desired file

– movie, photo or audio track.

Play Sound Via External Audio System or Headphones

Plug the audio system or headphones cable into the port on the back panel of

the TV. An audio system should be connected to the DIGITAL AUDIO OUT port, the

headphones – to the 3.5 mm audio port. Sound will be immediately played via

the connected device.

For detailed information refer to the “Connecting External Devices” section.

Using the Applications

You can start third-party applications on the TV, such as: browsers, media players,

online cinema applications, etc. Some of them are preinstalled; others can be

installed from the application store in the TV.

In order to start an application, in the Home Screen press , then select the desired

application. If the application is already installed, wait for it to start up. If the

application is not installed, press Install.

Transmitting Video Signal from Smartphone or Tablet

In the Home Screen, press and start the Screen Mirroring application. Then

activate the broadcasting function in the smartphone or tablet and select the TV

from the list of available devices.

For detailed information on screen mirroring refer to the operating documentation

of your smartphone or tablet.

Restart or Turn Off the TV

Press and hold the power button on the RC unit or the TV housing. The shutdown or

restart commands will appear on the screen – select the desired option.

5. TROUBLESHOOTING INSTRUCTION

Troubleshooting

If you experience any malfunctions during TV operation, turn it off and on again.

You can also use the table below to identify and eliminate malfunctions. If the

malfunction cannot be eliminated, contact a technical service center.

PROBLEM SOLUTION

The TV will not turn on (the

standby mode indicator does

not light)

Check connection of the TV’s power cable to the 220–240 V ~50/60

Hz power supply grid. Check for voltage in the electric socket.

Disconnect the power cable from the electric socket, wait for 2

to 3 minutes and plug it in again. Check operation of the RC unit

No TV signal reception

Check correctness of the TV setting. Select another TV channel.

Check correctness of antenna cable connection. There may be an

antenna failure or a temporary loss of transmitting station signal

No sound is played

Check sound volume setting.

Ensure that the sound is not muted with the button. Check

correctness of sound system selection in the channel settings.

Check correctness of the sound settings

Disturbed image color

rendering

Check correctness of color system selection in the channel

settings. Check correctness of the image settings. The signal

from the transmitting station may be weak or disturbed; select

a different channel

The TV cannot be controlled

from the RC unit

Open the RC battery compartment and replace the batteries.

Point the RC unit emitter directly at the RC sensor on the front

panel of the TV. There should be no obstacles (furniture items,

etc.) between the RC unit and the RC sensor of the TV. The distance

between the RC unit and the RC sensor of the TV should not exceed

5 meters, and the angle of deflection from the imaginary line

perpendicular to the screen should not exceed 20 degrees

Blinking image or stripes in

the PC

HDMI mode

Incorrect computer settings. Start up the computer in safe mode

and select the right screen settings

Individual small dots (pixels)

appear on the screen

This TV is equipped with a high-resolution LC screen matrix. The

modern matrix manufacturing technology allows for the occurrence

of individual small dark or colored dots (pixels) in the screen image,

which do not disturb the overall image perception. All matrixes

have been factory tested and comply with the industry standards

for this product group

The USB does not work

Disconnect the USB storage card (external USB device) from the

TV’s USB interface. Carefully reconnect the device

Some files on the USB device

cannot be read

The types of files readable via the USB interface should comply

with the specification. Ensure that the TV supports this type of

files (see the “Play Media Files from a USB Storage Device” section)

Crackling or humming sound

during operation or upon

shutdown

This is a normal occurrence caused by thermal contraction of the

plastic during temperature and humidity fluctuations. The TV can

emit a quiet humming noise caused by electric circuit operation.

This is not a malfunction

Slow response to control

commands

The TV requires a certain time for the proper execution of a control

command. Make a sufficient break between different control

inputs to ensure stable operation of the TV. This does not affect

the functionality of the TV and is not a malfunction

Online video playback is

jerky or retarded

Stop the playback, wait for 2 to 3 minutes, then resume the

playback. The wrong tariff plan may have been selected with

your Internet provider. It is recommended to use a tariff plan

with a minimum data transfer speed of 10 Mbit/s. The speed can

be reduced if additional wireless devices are connected to your

home WLAN router. Check the router specifications and settings,

replace the router in case of malfunctions

One of the installed

third-party applications

does not work (or operates

without sound, or has other

malfunctions)

The problem is probably related to the software (application) itself.

Try to start it again later or contact the customer support service

of the developer company.

The Manufacturer shall not be liable for the functioning of third-

party applications

Wireless mouse does not

work (cannot be controlled)

Install a new battery or replace the depleted wireless mouse

battery. Ensure that there are no obstacles between the mouse

and the transceiver connected to one of the TV’s USB ports and

these are located within “line of sight” from each other. Replace

the wireless mouse if necessary

An embedded menu

is missing, control

malfunctions occur

Disconnect the TV from power supply, wait for one minute and

plug it in again. Reset the TV to factory settings (see “Restore

Default Settings” section)

You have forgotten the login

and password of your Yandex

account

Use the suggestions in the Help section of Yandex.Passport: yandex.

ru/support/passport/troubleshooting/

Internet connection

problems

Ensure there are no connection problems on the part of the

Provider:

•

Try opening the yandex.ru website in a smartphone or

computer. If there is no access, restart the router. If this

does not help, contact your provider.

•

Connect the TV to mobile Internet via your smartphone. If

the TV connects and stably operates with a mobile Internet

connection, then the Wi-Fi connection problem is probably

related to your provider.

The Wi-Fi connection should be stable for proper TV operation.

Place the smartphone neat the TV and check the connection

signal strength. If the indicator shows less than half of the

maximum strength, move the TV closer to the router or connect

it with a cable (see “Re-Connect to the Internet”).

- Restart the TV (see “Restart or Turn Off the TV”).

Set up the Internet connection once again (see “Restart or

Turn Off the TV”)

Problems with the

Yandex.Plus or KinoPoisk

subscription

If you have a Yandex.Plus subscription – study the recommendations

on the website yandex.ru/support/plus/troubleshooting.html.

Information on KinoPoisk HD is available at yandex.ru/support/

kinopoisk/subscription-kinopoisk.html

Warning: do not allow the image in the screen to remain static for a prolonged

time. A high-contrast static image can leave a “shadow” on the screen. Usually

this “shadow” will gradually disappear then the TV is turned off. This malfunction

shall not be considered a guarantee case.

6. MAINTENANCE

Thorough and regular cleaning can extend the service life of your TV and prevent

possible problems. Always turn the TV off and disconnect it from the electric socket

before any cleaning activities. Use only dry cloth to clean the TV.

7. SPECIFICATIONS

Model CT-8585

Net/Gross Weight (kg) 38.2/54.9

VESA mount type 600х400/М8

Active screen size 85’’

Screen size ratio 16:9

Resolution 3840х2160

Frame rate (Hz) 60

Brightness (type: cd/m2) (nit) 400

Contrast ratio (standard) 5000:1

Viewing angles (L/R) 170

/170

Response time (TR+TF/TYPE) (ms) 8.5

Number of colors 1,07 G (8-bit+FRC)

Side panel CI, 2xUSB, 3xHDMI, EARPHONE
