iVigo EPK4550E05 8375 [16/328] Installation instructions

Wall Mounting

1. Open the packing box and take out the convector with its protective nylon cover. Tear the

protective nylon cover outside the box without giving any harm to the appliance and take out the

hangers attached on the unit by pulling the springs thereon.

2. Correct space has to be measured n order that the connecton cord can easly be connected to

the electrc socket. After determnng the place the holes for montage must be drlled accordng to

the method shown n Fgure 7. To fx ths applance you can use the wall mountng bracket. (Fgure

5) Mountng bracket can be used as a template for postonng and drllng ponts. You can place

the bracket on the wall and measure the space between the oor and the lower part of the bracket

as mn 100 mm or max. 200 mm. Mark the screw-holes through the holes wth an approprate

pen. You have to be careful to ensure the safety zones are kept free n order that the applance can

work ecently. (Figure 6.)

3. After marking the points, the holes will be drilled by a Ø9 mm drill and the plastic dowels that

are in the montage items are driven to these holes.

4. Wall mounting brackets supplied with the unit has to be xed securely to the wall.

Note: By adding the requested height dierence to these measures the height can be arranged

as demanded.

2. INSTALLATION INSTRUCTIONS

Dowel

Lower Mount

Spring

Clip

Screw

(H)

Model A H (min/max)

EPK4550 280 mm (28 cm)

100/200 mmEPK4570 400 mm (40 cm)

EPK4590 600 mm (60 cm)

Figure 5. Wall mounting

brackets

207

Figure 7.

Centering

holes

Figure 6. Minimum safety zones

required for the eciency of the

appliance
