ENGLISHen
14
7.1 Chip blower
Optional blower for a clear view of the cutting line.
On:Press the switch button (11) on the left side of
the machine. (look for the symbol).
Off:Press the switch button (11) on the right side of
the machine. (look for the symbol).
7.2 Adjusting the pendulum motion
Set the required pendulum motion using the
adjustment lever (10).
Position "0" = pendulum motion is switched off
. . .
Position "III" = maximum pendulum motion
See page 3 for recommend setting values.
The best way to determine the ideal setting is
through a practical trial.
7.3 Setting maximum speed
Set the machine to maximum speed using the
setting wheel (15). This can also be done during
operation.
See page 3 for recommend setting values.
The best way to determine the ideal setting is
through a practical trial.
7.4 On/Off switch, continuous activation
Avoid inadvertent starts: always switch the
tool off when the plug is removed from the
mains socket or if there has been a power cut.
In continuous operation, the machine
continues running if it is forced out of your
hands. Therefore always hold the machine with
both hands using the handle provided, stand
securely and concentrate.
Switching on: push the sliding switch (12)
forwards. For continuous operation, now tilt it
downwards until it engages.
Switching off: press the rear end of the slide switch
(12) and release it.
Clean the machine regularly. This includes
vacuum cleaning the ventilation louvres on the
motor.
Clean the saw blade clamping fixture (2) regularly
and thoroughly by blowing with compressed air.
If necessary, clean the openings behind the saw
blade support roller (3).
Apply a drop of oil to the saw blade support roller (3)
from time to time.
Plunging
The jigsaw blade can plunge into workpieces made
from thin, soft materials without the necessity of
drilling a hole beforehand. Only use short saw
blades. Only at 0° angle setting.
See illustration on page 2. Set the adjustment lever
(10) to the "0" position (pendulum motion is
deactivated). Position the jigsaw with the front edge
of the footplate (6) on the workpiece. Hold the
operating jigsaw firmly and guide slowly
downwards. Once the saw blade has penetrated
the workpiece, the pendulum motion can be
activated.
In thicker workpieces, a hole for inserting the saw
blade must be drilled first.
Use only genuine Metabo accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating
instructions.
Fit accessories securely. If the machine is operated
in a holder: secure the machine well. Loss of control
can cause personal injury.
See page 4.
A Circular-cutting and parallel guide
B Protective plate (prevents workpieces with
sensitive surfaces from becoming scratched)
10.1 Attaching the circular-cutting and
parallel guide
For sawing circles (dia. 100 - 360 mm) and making
cuts parallel with edges (max. 210 mm).
Attach circular guide (see Fig. I)
- Slide the rod on the circular-cutting and parallel
guide sideways into the footplate (centre point (c)
faces downwards).
- Set the desired radius (d).
- Tighten screw (b).
- Turn the button in such a way that the rear centre
point (c) in direction of sawing is extended. Insert
it into the centre of the circle.
Attach parallel guide (see Fig. II)
- Slide the rod on the circular cutting and parallel
guide sideways into the footplate
(the centre point (c) faces upwards).
- Set the dimension (e)
- Tighten screw (b).
In order to minimise saw blade drifting, we
recommend using extra-thick saw blades: 6.23694,
6.23679, 6.23685
For a complete range of accessories, see
www.metabo.com or the catalogue.
Repairs to electrical tools must ONLY be
carried out by qualified electricians!
Contact your local Metabo representative if you
have Metabo power tools requiring repairs. See
www.metabo.com for addresses.
You can download a list of spare parts from
www.metabo.com.
7. Use
8. Cleaning, Maintenance
9. Tips and Tricks
10. Accessories
11. Repairs
