English
3
DCH263
Voltage V
DC
18
Type 1
Battery type Li-Ion
No-load speed min
-1
0–1165
No-load Impact rate bpm 0–4300
Single impact energy (EPTA 05/2009) J 3.0
Maximum drilling range in steel/wood/concrete mm 13/30/28
Maximum core drilling capacity in soft brick mm 65
Chuck SDS PLUS
Collar diameter mm 54
Weight (without battery pack) kg 2.7
Noise values and vibration values (triax vector sum) according to EN60745-2-6:
Hammerdrill mode
L
PA
(emission sound pressure level) dB(A) 86
L
WA
(sound power level) dB(A) 97
K (uncertainty for the given sound level) dB(A) 3
Chisel mode
L
PA
(emission sound pressure level) dB(A) 89
L
WA
(sound power level) dB(A) 100
K (uncertainty for the given sound level) dB(A) 3
Drilling into concrete
Vibration emission value a
h, HD
= m/s² 9.1
Uncertainty K = m/s² 1.5
Chiselling
Vibration emission value a
h
,
Cheq
= m/s² 7.7
Uncertainty K = m/s² 1.5
Drilling into metal
Vibration emission value a
h
,
D
= m/s² <2.5
Uncertainty K = m/s² 1.5
Screwdriving
Vibration emission value a
h
= m/s² <2.5
Uncertainty K = m/s² 1.5
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
EC-Declaration of Conformity
Machinery Directive
Heavy-Duty Cordless Rotary Hammerdrill
DCH263
DeWALT
declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN60745-1:2009+A11:2010, EN60745-2-6:2010.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact
DeWALT
at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of
DeWALT
.
Markus Rompel
Vice-President Engineering, PTE-Europe
DeWALT
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
07.01.2019
The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in EN62841 and may be used to
compare one tool with another. It may be used for a preliminary
assessment ofexposure.
WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/
or noise should also take into account the times when the
tool is switched off or when it is running but not actually
doing the job. This may significantly reduce the exposure
level over the total workingperiod.
Identify additional safety measures to protect the
operator from the effects of vibration and/or noise such
as: maintain the tool and the accessories, keep the
hands warm (relevant for vibration), organisation of
workpatterns.
English (original instructions)
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough
product development and innovation make
DeWALT
one of the
most reliable partners for professional power toolusers.
Technical Data
HEAVYDUTY CORDLESS ROTARY HAMMERDRILL
DCH263
