13EN
EWD3 WIRELESS MAGNETIC DOOR CONTACT/SHOCK SENSOR/FLOOD SENSOR-READY
TERMS OF USE
The following terms and condiions govern use of the EWD3 device and contains important informaion on limitaions regarding the product’s use and
funcion, as well as informaion on the limitaions of the manufacturer’s liability.
Please carefully read these terms and condiions. For more informaion on your product, please visit eldesalarms.com
TECHNICAL SUPPORT
In order to ensure coninuous and proper operaion of the EWD3 device and uninterrupted service, it is the responsibility of the User to make sure that:
(I) the product is properly installed, and (II) there is constant electrical supply (low batery must be replaced in ime). If you experience diiculty during
the installaion or subsequent use of the system, you may contact “ELDES, UAB” distributor or dealer in your country/region. For more informaion
see eldesalarms.com
SAFETY INSTRUCTIONS
Please read and follow these safety guidelines in order to maintain safety of operators and people around:
• DO NOT use the device where it can cause potenial danger and interfere with other devices – such as medical devices.
• DO NOT use the device in hazardous environment.
• DO NOT expose the device to high humidity, chemical environment or mechanical impact.
• DO NOT atempt to repair the device yourself – any repairs must be carried out by fully qualiied personnel only.
• EWD3 can be powered by a single Primary 3V Lithium 1500mAh CR123A batery. When insering the batery into the batery slots, mind
the polarity terminals!
• A blown fuse cannot be replaced by the user. The replacement fuse has to be of the kind indicated by the manufacturer (fuse F1 model –
PICOSMDC050S).
• The device is not meant for outdoor use, i.e. you should use it inside a building. Protect the device against cold, heat and keep away from
direct sunlight while in storage or operaion.
WARRANTY PROCEDURES
Warranty and out of warranty service should be obtained by contacing the system integrator/dealer/retailer/e-tailer or distributor where the
customer purchased the product. When requesing for service, the proof of purchase and the product serial number must be provided. The return
of the defecive product should be strictly through the original route of purchase, and the customers shall pack the product appropriately to prevent
the returned product from sufering in the transportaion.
MANUFACTURER WARRANTY
“ELDES, UAB” warrants this system only to the original purchaser and only in case of defecive workmanship and materials under normal use of
the system for a period of twenty four (24) months from the date of shipment by the “ELDES, UAB” (Warranty Period). Warranty obligaions do
not cover expandable materials (power elements and/or bateries), holders and enclosures. The warranty remains valid only if the system is used
as intended, following all guidelines outlined in this manual and in accordance with the operaing condiions speciied. The warranty is void if the
system has been exposed to mechanical impact, chemicals, high humidity, luids, corrosive and hazardous environments or force majeure factors.
If a hardware defect arises and a valid claim is received within the Warranty Period, at its own discreion, “ELDES, UAB” will either (a) repair a
hardware defect at no charge, using new or refurbished replacement parts, or (b) exchange the product with a product that is new or which has
been manufactured from new or serviceable used parts and is at least funcionally equivalent to the original product, or (c) refund the purchase
price of the product.
LIMITED LIABILITY
The buyer must agree that the system will reduce the risk thet, burglary or other dangers but does not provide guarantee against such events.
“ELDES, UAB” will not assume any responsibility regarding personal or property, or revenue loss while using the system.
