TOOL PARTS OVERVIEW

OPERATION

12. Blade guard lever

13. Depth adjustment scale

14. Depth adjustment lever

15. Rip fence

17. Rip fence lock knob

20. Mobile blade guard

22. Lock-o button

23. Bevel scale

25. Bevel adjustment lever

PRIOR TO INITIAL OPERATION

• Make sure the power supply voltage corresponds to the value indicated on the name

plate with technical data of the tool.

• Always check the position of ON/OFF switch. The power tool must be connected to the

power supply socket only when this switch is in OFF position. If the plug is connected

to a receptacle while the power switch is in the ON position, the power tool will start

operating immediately, which could cause a serious accident.

• Make sure that the cord and the plug are in order. If the replacement of the supply cord

is necessary, this has to be done by the manufacturer or his agent in order to avoid a

safety hazard.

• Always inspect the blade. Use only well grinded blades. Never use blades with cracks

and indents or HSS-blades.

• Check if the blade is tightened reliably and moves freely.

• Check if the mobile guard moves freely.

• Make sure the work piece or the material is well secured.

• Let the machine operate at no load for 30 seconds. Replace the blade in case vibrations

are observed.

REPLACING THE BLADE

• Use the saw blade wrench to apply counterpressure to the ange (3).

• Using the allen key delivered with the machine, turn bolt (4) anti-clockwise. Remove

the blade bolt (4) and the outer blade ange (3).

• Ensure blade anges and bolt is clean of sawdust, grease, etc.

• Move the lower blade lever (12), to lift the lower guard (20) toward the upper blade

guard (6). While performing this step check the proper functioning of the lower guard

spring.

• Make sure the blade teeth and arrow on the blade (1) point in the same direction as the

arrow on the upper blade guard (6).

• Slide the new blade (1) through slot in the base plate (5) and mount it against the inner

blade ange (3a) on the shaft. Make sure the large diameter of the blade anges lay

ush against the blade (1).
