REVERSE OSMOSIS SYSTEM INSTALLER AND USER GUIDE

1. PURPOSE OF THE PRODUCT

Inside the membrane, water is separated into two streams: concentrate, which is discharged into

drain, and permeate, which enters pressure tank 2 for storage. The tank is connected to the output

through the membrane auto shut-o valve and check valve built into the transion ng that is

installed in the permeate outlet of membrane housing. Aer the auto shut-o valve is installed the

union tee, through which the tank is connected to the lter rack with the yellow tube. On the top of

the tank, tank valve 6 is installed.

Pressure tank of the system accumulates puried water. Without it, reverse osmosis membrane

wouldn’t be able to produce sucient ow for direct water consumpon. For example, if the lter had

an installed membrane with a performance of 50 GPD (7.9 L / h), it would take over 1.5 min to ll the

glass of 200 ml or 2 min for the 9 oz glass. Thus, the system stores puried water in the tank and delivers

it to the user as needed, and then generates a supply of water. Time required to ll empty tank can range

from 1.5 to 3 hours. Aer the tank has been lled the auto shut-o valve shuts o the water supply from

the pre-lters and the unit stops. Aer opening puried water faucet 3, the pressure of water in the

tank lowers, and the auto shut-o valve automacally resumes the ow of water through the pre-lter

cartridges to the membrane to re-ll pressure tank. Water with retained impuries (concentrate) is dis-

charged into drain through the concentrate outlet, connected with black tube to drain saddle 8, which

is installed on drain pipe. In order to create backpressure, which is required to maintain the operang

pressure inside the membrane housing, ow restrictor 14 is installed in the black tube. Flow restrictor is

a plasc insert with precision bore capillary. The ow restrictor is inserted inside the end of black tube

that is ed in the membrane concentrate outlet.

When drawn from the faucet, puried water runs from the pressure tank through the union tee

through to the h stage of puricaon—carbon post-lter, intended for the nal puricaon of

water. It contains high quality acvated carbon made from coconut shell. This lter improves and

renes avor of puried water. Carbon post-lter is connected with blue tube to the drinking water

faucet 3 mounted on sink or counter.
