(8) Cable Connection
1) Power Button and LED Cable
2) Top Panel I/O Port Cable
Tip
▶ To connect USB 2.0, 3.0, 3-SATA and audio cables, please refer to the motherboard
manual.
▶ When the +/- polarities are reversed, the LED’s will not function.
Power LED
Power
Motherboard side
Power Button Side
HDD LED
Reset
or
HD Audio
Motherboard side
Top Panel I/O Port side
Audio
USB 2.0 USB 3.0
e-SATA
AC ’97
