Zalman GS1200 [3/19] Gs1200
![Zalman GS1200 [3/19] Gs1200](/views2/1111215/page3/bg3.png)
1
1
Eng
GS1200
Cautionary Notes
1) Please read this manual thoroughly prior to installation.
2) Before installing, check the components and condition of the
product, and if any problem is found, contact the retailer.
3) Avoid inserting objects or hands into the system while it is in
operation to prevent product damage and injuries.
4) Check the manual when connecting cables. Incorrect connections
may cause short circuits leading to re hazards.
5) Do not block the Front Intake Vent or the Rear Exhaust Vent.
6) Keep this unit away from heat sources, direct sunlight, water,
oil, and humid environments, and place the unit on a flat, stable,
vibration-free, and well-ventilated area.
7) Do not clean the product surface with chemicals or wet cloth.
(chemicals: industrial brightener, wax, benzene, alcohol, paint
thinner, mosquito repellent, aromatics, lubricant, detergent etc.)
8) Please wear gloves while handling this product to prevent injuries.
9) Product design and specications may be revised to improve quality
and performance.
Disclaimer) Zalman Tech Co., Ltd. is not responsible for any damages due to
external causes, including but not limited to, improper use, problems
with electrical power, accident, neglect, alteration, repair, improper
installation, or improper testing.
Содержание
- Cautionary notes 3
- Gs1200 3
- 1 specifications 4
- 2 product information 4
- Front top side left 4
- Gs1200 4
- Product details 4
- 3 top panel i o ports and hdd docking station 5
- Gs1200 5
- 4 exploded view 6
- Gs1200 6
- 5 parts 7
- Gs1200 7
- Installation 8
- 3 psu installation 9
- Gs1200 9
- Type a type b 9
- 4 motherboard installation 10
- Atx board 10
- Gs1200 10
- Gs1200 12
- Hdd installation to hdd tray 12
- Adapter tray installation 14
- Gs1200 14
- ① adapter tray removal 14
- ② drive installation to adapter tray 14
- Gs1200 15
- Top hdd docking station 15
- Be connected to the hot swap pcb 16
- Caution 16
- For hdd stability please power the system off before removing the hdd frequent installation and removal of an hdd can wear connectors 16
- Gs1200 16
- Hot swap pcb 16
- Pcb s zm hs100 can be purchased separately 16
- The fan controller enables selection of 12v or 5v power source 1 hot swap pcb comes standard at the bottom of the case additional hot swap 16
- The s ata connectors connect in a a b b c c configuration to use the hot swap feature the s ata cable s and the 4 pin power cable must 16
- ① rear 16
- ② front 16
- 8 cable connection 17
- Gs1200 17
- Power button and led cable 17
- Top panel i o port cable 17
- 1 side cover fan 20 18
- 2 bottom panel optional fan 12 18
- Gs1200 18
- Optional 18
- Optional fan installation and replacement 18
- Standard 12 18
- 3 hdd cover tray fan removal 19
- Caution 19
- Gs1200 19
- Open the hdd cover and remove the fan bracket before uninstalling the bracket from the fan 19
