Zalman GS1200 [6/19] 4 exploded view
![Zalman GS1200 [6/19] 4 exploded view](/views2/1111215/page6/bg6.png)
4
GS1200
# Part Name Units
① HDD Tray 6
② HDD Tray Cover 2
③ Front Cover 1
④ Stand (front) 1
⑤ Stand (rear) 1
⑥ PSU Support 1
⑦ PSU Bracket 1
# Part Name Units
⑧ Side Cover (right) 1
⑨ Side Cover (left) 1
⑩ Top Cover 1
⑪ Chassis 1
⑫ 5.25” Bay Cover 3
⑬ Adapter Tray 1
(4) Exploded View
①
②
③
④
⑤
⑥
⑦
⑧
⑩
⑪
⑫
⑬
⑨
