7
Eng
GS1200
Tip
▶ Type A (PSU independent cooling)
If the PSU’s fan points downwards, the PSU’s cooling performance is
enhanced.
▶ Type B (Case Air Circulation Type)
If the PSU’s fan points inwards, the PSU’s cooling performance is
enhanced.
※ When using the case in a dusty environment, use Type B.
(3) PSU Installation
Type A Type B
Type A Type B
Or
B Bolt
