5) Check for leakage at each connector. Leakage can lead to short-circuit and damage of

the motherboard and other components.

6) If leakage occurs, immediately stop the pump, clean the leakage area with tissue paper,

and reassemble the leakage area.

7) If there is no leakage, remove the power Jump Cable of the power supply’s main connector.

Now connect the power supply’s main connector to the motherboard’s power connector,

and operate the PC. (connect the disassembled CPU 4-Pin connector as it originally was.)

Note 1) Power must always be supplied to the Reserator’s AC cable in order for the Reserator

and the PC to be run at the same time. Must check to see if the power is constantly

being supplied to the AC cable.

Note 2) Using the Reserator AC power and the PC power on the same multi-tab is recommended.

Note 3) After the test run is complete and everything is functioning properly, must check to

see if the Reserator’s DC cable is connected to the power supply’s 4-Pin connector.

5. 16 Front Panel Controller Functions

1) Flux Check

Warning sound will go off and the red LED will flicker when the flux falls below a certain

level due to a problem in pump, leakage, or other problems. Detection of these problems

allows prevention of damage.

2) Simultaneous Operation with PC

By supplying power to the AC Cable, and by connecting the DC Cable to the 4-Pin Connector

of the Power Supply, it can operate in accordance with the PC power’s ON/OFF, which

allows ease and simplicity in use.

3) Light ON/OFF

The Blue LED will turn on if the Light/Reset button is shortly pressed, and the Blue LED

will turn off if the Light/Reset button is pressed again. This allows the users to be able to

quickly check whether the product is in use or not.

4) Flow Indicator

The coolant flow can be observed with naked eyes by seeing the Flow Indicator with its

integrated impeller, and bright Blue LED produces an elegant feel.

5. 15 How to Use the Front Panel Controller

1. Supply power to AC cable, and connect DC cable with 4-Pin connector

2. Supply Power to PC Warninig Sound, RED LED Turn off

3. PUMP Operates and Blue LED

Lights up

Press onto the Right/Reset Button

for More than five seconds

If Problem is

encountered

If no Problem

is encountered
