RESERATOR 2
6
※
The specifications of any product may change without prior notice to improve performance.
3. Installation Overview
DC Cable
Power Supply
4-Pin Connecter
CPU
Water
Block
VGA
Water
Block
I/O Bracket
Quick Coupling
AC Cable
