The specifications of any product may change without prior notice to improve performance.
2
Korean Patent Application No. 00-54635
Korean Design Applications Nos. 02-17470, 02-25208, 02-25209 etc.
Patent Applications pending in over 20 nations around the world, including USA, EU, and Japan
4. Patents
1) Common Components
❶
FHS Assembly (CNPS7000B-AlCu/Cu)
❷
Four (4) Bolts (for installing the FHS)
❸
Thermal Grease
❹
Fan Speed Controller (FAN MATE 2)
❺
Double - sided Tape (for installing FAN MATE 2)
❻
Cable for FAN MATE 2
❼
User’s Manual (in English and Korean)
❶
❽
❾
❿
❷
❹
❸
❺
❼
❻
5. Components
2) Components for Intel Pentium 4 (Socket 478)
❽
Two (2) Clip Supports For Socket 478
3)
Components for AMD Duron / Athlon / Athlon XP /
Sempron (Socket 462)
❾
One (1) A-Type (blue) Clip Support for Socket 462
❿
One (1) B-Type (white) Clip Support for Socket 462
Four (4) Bolts (for fastening the Clip Supports)
One (1) set of Washers
4)
Components for AMD Sempron / AMD64 (Socket 754/939/940)
Two (2) Nipples
One (1) Backplate for AMD64
Small washers (from component
)
Precautions
1) If excessive force is exerted on the fan, it may malfunction and result in damage to the product and/or the computer.
2) Do not put your finger in the fan while it is running.
3) Keep the product away from children.
4) Check the components list and condition of the product before installing. If there is any problem, contact the shop
where you purchased it and get a replacement or refund.
5) The exposed core of a Socket 462 CPU can be cracked if proper care is not taken. Read the “Installation” section
thoroughly before installing.
NOTICE) Zalman Tech Co., Ltd. is not responsible for any damages due to external causes, including but not
limited to, improper use, problems with electrical power, accident, neglect, alteration, repair,
improper installation, or improper testing.
