Zalman CNPS7000B-Cu LED [8/9] Notes on usage

※

The specifications of any product may change without prior notice to improve performance.

1) Installing FAN MATE 2 on the Inside of the System 2) Installing FAN MATE 2 on the Outside of the System

※FAN MATE 2 Installation and Usage

11. Thermal Resistance (℃/W) & Noise (dB) Curve

Connect the appropriate 3-pin connector on the

cable to the motherboard fan header and the

CNPS7000B’s fan connector.

Pull the 6-pin connector out of the system through

the back and connect it to FAN MATE 2, which

should be installed on the case using the included

double-sided tape.

◆

When the speed control knob on FAN MATE 2 is turned fully counter-clockwise, the fan operates in Silent Mode.

Turned fully clockwise, it operates in Normal Mode. You can select the desired fan speed by turning the knob.

Note) FAN MATE 2 has been specifically designed for the fan of this product. Zalman Tech Co., Ltd. is not

responsible for any damage to systems or CPUs caused by using it with other types of fans.

10. Notes on Usage

1) Checking CPU Compatibility

Please refer to “Compatible CPUs” on page 3 to confirm that your CPU is compatible before using the CPU cooler.

2) Cautions During Booting

When booting the computer, it may automatically power down after an alarm sound by a system

monitoring program to indicate that the CPU fan is rotating slowly. If this happens, turn the speed

control knob fully clockwise to increase the fan speed. Then set ‘CPU Fan Detected’ to ‘Disabled’ in the

BIOS settings, or set the slowest rotational speed of the CPU fan in the system monitoring program to

less than or equal to 1,300rpm.

Note) Some motherboards do not boot if the rotational speed of the CPU fan is below a certain

rpm. If the BIOS settings are updated, Silent Mode can be used. For more information on

updating your BIOS, please refer to your motherboard manufacturer's website. Disabling

CPU fan speed detection in BIOS settings does not affect computer performance.

3) Overclocking

The fan should be set to Normal Mode if Overclocking.

(Zalman Tech Co., Ltd. is not responsible for any damage resulting from CPU Overclocking.)

Fan Connector

(CNPS7000B)

Motherboard

Double-sided Tape

FAN MATE 2

6-Pin Connector
