Technology
Incredibly light, SPACE speakers are innovative components which insure state-of-the-art
performance in very small locations.
The heart of these drivers is their motor assembly, which combines breakthrough technical
solutions and exclusive materials. The REN
®
Rare Earth Neodymium magnet uses very
powerful, high thermal threshold neodymium. The study of magnetic field lines distribution
led to the development of SFE
®
Symmetrical Field Engine, for excellent transfer energy and
maximum linearity even at extreme excursions.
The stiff, yet very light anti-vibration composite polymers basket houses RCD
®
Radial
Cooling Ducts forced ventilation circuit, which keeps voice coil temperature constant. Its
very wide rear ports provide membrane with minimum radiation impedance, eliminating
noise and distortion. DWR
®
Surround allows mobile voice coil long, linear excursion.
The tweeter employs an innovative double REN
®
magnetic circuit, a copper short circuit ring
and two different, interchangeable acoustic chambers, called BSB
®
Back Sealed Box. They
optimise frequency response according to different installation and filter needs.
The 28mm, soft Tetolon
®
dome insures natural, clear, detailed sound. Special attention was
paid to the study of which glues to use for assembling membrane and voice coil former, in
order for the speaker response to be flat, smooth even at very high frequencies.
BSC
®
Best Sound Control innovative technology optimises the system sound in any car
compartments and for any listening positions. Crossovers employ the highest-grade
components, like the new TR
®
Triple Resistor Heat Sink, which increases power handling
notably improving, thus, acoustic results.
The unique technical solutions used in SPACE speakers, together with the designers’
commitment when developing and tuning them, give a new definition to drivers development
standards. This is witnessed and proved by the important EISA award, which these products
deserved for their cutting-edge technology.
