Tascam CD-X1700 [10/48] English 2 functions and controls

English 2. Functions and Controls

10 TASCAM CD-X1700 DUAL CD PLAYER

, Remote Connector

Connect this to the REMOTE connector on the rear

panel of the main unit.

… DO NOT use any cable except the cable

supplied with the CD-X1700.

WARNING

… Connect the cable to the CD-X1700 as

shown on the illustration on the rear

panel. If you connect the cable in any

other way, you may damage the CD-

X1700.

2-4. Remote Controller (Bottom Panel)

x IN and OUT keys

Use these keys to record and clear the sampled

sound. When you have recorded the sample, these

keys will light. Start and stop sample playback

using these keys. (∑ page 17)

Pressing and holding the IN key then using the Jog

wheel controls the sampler output level.

c LOOP and REV LEDs

Indicates the sampler playback mode. (∑ pages 17

- 18)

v KEY ORIG / KEY key

Turns the KEY ORIGINAL function on and off.

(∑ page 14)

Sets the key control value. (∑ page 15)

b TEMPO / BANK key

Selects the tempo range, either +/-8, 16, 32, 100 or

0%.

Selects the track memory bank from A to E.

(∑ page 18)

n BEND +/ A.RDY, –/A.CUE keys

Use these keys to perform pitch bending.

(∑ page 14)

Turns the AUTO CUE function on and off.

(∑ page 20)

Turns the AUTO READY function on and off.

(∑ page 20)

m TEMPO slider

Changes the playback tempo. (∑ page 14)
