Thermaltake Max4 Active Cooling [4/8] Esata extended pci bracket
![Thermaltake Max4 Active Cooling [4/8] Esata extended pci bracket](/views2/1118614/page4/bg4.png)
g
Power Switch
f
Power Port
a
SATA Cable
b
eSATA Port
c
LED Light
d
USB Port
1.5 System Requirement
1.4 Technology Specification
1.3 Features
1.6 Appearance
b
a
Note:Your motherboard's chipset may have to support SATA2 hot-plug if you want to
enable the hot-plug function.
The following chips support hot-plug:Intel ICH6R ICH7R VIA 8237R
NVIDIA Nforce series ATI series SiliconImage SIS ULI or any support AHCI hot-
plug function.
eSATA Extended
PCI bracket
e
eSATA Port
i
Foot Stand
h
8015 Fan
d
e
f
g
c
h
i
- Silent Fan: Cooling by 8015 blue LED fan.
- Dual Interface: Supporting eSATA & USB2.0 interface.
- Massive Capacity: Maximum support up to 1.5TB HDD.
- PC and Mac Compatible
80x80x15mm
0.16A
12V
1500 RPM
20 dBA
Fan Dimension
Current
Voltage
Fan Speed
Noise
P/N
Case Type
Fan Type
Weight
Dimension
Material
Interface
SATA compatibility
Transfer rate
N0012US
3.5" SATA HDD
80 x 80 x 15mm Fan
425g
215 x 134 x 30mm
Aluminum & Plastic
SATA to eSATA SATA to USB2.0
SATAII SATAI
Up to eSATA-3Gbps & USB2.0-480Mbps
1) External Power Adapter (12 V / 2.0A)
2) UL, FCC, CE, CSA Certified
eSATA External Cable
USB2.0 Cable
SATA to eSATA PCI Bracket
Power Adapter
Foot Stand
Power Source
Accessories
3 4
PROJECT/ N0012US_Max 4 Active Cooling_
VERSION/ A PAGE/ 1/1
DATE/ 090121
10516
(G)
MARKETING CHECK DESIGN
PRODUCT GM
Peipei
(
125mm
176 mm
