![Thermaltake Max4 Active Cooling [7/8] Project n0012us_max 4 active cooling_](/img/pdf.png)
Thermaltake Max4 Active Cooling [7/8] Project n0012us_max 4 active cooling_
![Thermaltake Max4 Active Cooling [7/8] Project n0012us_max 4 active cooling_](/views2/1118614/page7/bg7.png)
2
3
Connect the
eSATA cable
from PCI bracket
to enclosure and
connect power cable
Then turn on.
Connect the SATA connector of the
extended bracket to the motherboard's
SATA port.
1
2.3 eSATA PCI Bracket Installation
Install the eSATA PCI extended
bracket to the chassis.
If your motherboard or case including eSATA port,
please connect by eSATA cable directly.
9 10
Note
PROJECT/ N0012US_Max 4 Active Cooling_
VERSION/ A PAGE/ 1/1
DATE/ 090121
10516
(G)
MARKETING CHECK DESIGN
PRODUCT GM
Peipei
(
125mm
176 mm
