Manuale d’uso | Owner’s manual
Gentile Cliente,
complimenti per aver acquistato un prodotto Hertz SPL SHOW. La vostra
soddisfazione è il primo requisito cui devono rispondere i nostri prodotti: la stessa
soddisfazione di chiunque voglia vivere l’emozione del car audio.
GLI ALTOPARLANTI HERTZ SPL SHOW SONO IN GRADO DI CREARE SISTEMI AUDIO
AD ALTA POTENZA CHE POSSONO GENERARE ELEVATISSIME PRESSIONI SONORE
INDISTORTE. RICORDATE CHE PROLUNGATE ESPOSIZIONI AD UN LIVELLO
ECCESSIVO DI PRESSIONE ACUSTICA POSSONO PRODURRE DANNI AL VOSTRO
UDITO; UTILIZZATE DUNQUE EQUILIBRIO E BUON SENSO NELL’ASCOLTO.
La sicurezza durante la marcia deve restare sempre al primo posto. In ogni
situazione il volume d’ascolto deve avere un livello tale da non coprire i rumori
provenienti dall’esterno; dovreste essere in condizione di udire anche quelli del
Vostro veicolo per affrontare prontamente situazioni di emergenza.
Per ottenere il massimo delle prestazioni dal Vostro nuovo componente. Vi
consigliamo di seguire attentamente le istruzioni del presente manuale. La realizzazione
di un sistema hi-fi car di alto livello richiede una buona conoscenza delle problematiche
meccaniche ed elettriche delle autovetture; qualora riteneste di non possedere gli
attrezzi necessari o la conoscenza adeguata, non esitate a contattare un installatore
specializzato. Un’installazione a regola d’arte Vi assicurerà prestazioni entusiasmanti e
coinvolgenti, senza influire sulla sicurezza e l’affidabilità della Vostra autovettura.
Questo manuale è stato redatto per fornire le indicazioni principali e necessarie
all’installazione e all’uso del sistema. La varietà delle applicazioni possibili è tuttavia
molto ampia; per avere ulteriori informazioni non esitate a contattare il Vostro
rivenditore Hertz o l’assistenza ufficiale Hertz via mail, scrivendo direttamente agli
indirizzi:
Per l’Italia - supporto.tecnico@elettromedia.it - Per l’estero - support@elettromedia.it
SAFE SOUND
Dear Customer,
Congratulations for purchasing a product of the Hertz SPL SHOW line. Your satisfaction
is the first requirement that our products must meet: the same satisfaction as that of
those who long for the car audio emotion.
THE HERTZ SPL SHOW LOUDSPEAKERS ARE DESIGNED FOR HIGH POWER
AUDIO SYSTEMS WHICH CAN GENERATE VERY HIGH UNDISTORTED SOUND
PRESSURE. PLEASE REMEMBER THAT LONG EXPOSURE TO AN EXCESSIVELY
HIGH SOUND PRESSURE LEVEL MAY DAMAGE YOUR HEARING; THEREFORE ,
PLEASE USE COMMON SENSE AND PRACTICE SAFE SOUND.
Safety must be at the first place while driving. In every situation, the listening volume
should not cover the noise coming from outside the car; You should also be able to hear
the noise generated by Your car in order to promptly face any emergency.
In order to get the best performance from Your new speaker we recommend you carefully
follow the instructions herein. In order to make a top level car hi-fi system, You need to
know the car mechanical and electrical issues very well; if You think You lack the required
tools or the sufficient knowledge, please contact a specialty installer. A workmanlike
installation will ensure You exciting, enthralling performance, without affecting Your car’s
safety and reliability.
This manual has been drawn to provide the main instructions required to install and use
the system. However, the range of possible applications is very wide; in order to get further
information, please contact Your Hertz dealer or the Hertz authorized service by sending
an e-mail directly to the following email address:
Italy - supporto.tecnico@elettromedia.it - Worldwide - support@elettromedia.it
INDICE / TABLE OF CONTENTS
Safe Sound / Safe Sound 2
Indice / Table of contents 2
Technical specifications 3
Ingombro / Size 4
Collegamento / Connecting 5
Distanze e inclinazione / Suggested length and angle 6
Montaggio incassato / Flush mounting 6
Esempi di collegamento / Connection patterns 7
Filtraggio / Filtering 7
Quick Start Guide 8
TECHNICAL SPECIFICATIONS
Component
Size
mm (inch)
Sensitivity
dB/SPL
Magnet
Dome / Cone
Weight of
one component
kg
mm
Ø Voice coil
Impedance
Ω
Frequency
response
Hz
Power
handling
peak
continuous
Outer
diameter
mm
A
Mounting
diameter
mm
B
mm
Total depth
C
mm
Mounting
depth
D
High Efficiency
Compression Driver
25 (1”)
100 W
Hi-pass filtered
5 kHz @ 12 dB Oct.
4
3k ÷ 20k
107
58,5
43,5
67
33,5
0,52
25
Neodymium REN
®
Aluminium
ST 25
CIFICATIONS
BA
D
C
Bullet Tweeter
2
