Hertz ST 25 [3/16] Tweeter

Hertz ST 25 [3/16] Tweeter
TWEETER
TWEETER
Ingombro / Size
A
Ring 1 Ring 2
C
D
B
58,5 43,5 67 33,5
A B C D
2”
5/16
1”
3/4
2”
11/16
1”
5/16
ST 25
Misure espresse in mm e pollici / Measures in mm and inches
Manuale d’uso | Owner’s manual
Ring 2Ring 1
Max 20 mm
Min 34 mm
Ø
45 mm
Montaggio incassato / Flush mounting
Ring 2
Ring 1
Distanze e inclinazione / Suggested Length and Angle
A = B
If necessary use the
supplied capacitor
If necessary
use the
supplied
capacitor
4 5
