13 RESET OPERATION Fig 2 2 AUTO POWER OFF STANDBY MODE 1 Hold down Q for 3 seconds until the display digits are cleared The computer will reset the stored TRIP DIST and TIMED TRIP data back to u A A reset operation does not reset the ODO data To preserve battery power the computer will automatically power off to standby mode after 15 minutes Standby mode displays only the clock Normal operation will be returned on by pressing 0 once whilst in standby mode Fig 2 2 AUTOMATIC START STOP not U U I 0IJO 3 seconds no RESETS TRIP DIST 8 TIMED TRIP The computer will automatically begin counting data upon riding and stop counting data when riding is stopped A In order to automatically begin counting the computer must not be in standby mode
