17 2 Ensure the SENSOR text is located on the wheel side of the fork to ensure a close proximity to the spoke magnet 3 Ensure the arrow on the silicon housing is pointing upward towards the main unit 4 Pull the silicon strap around the fork and fit it over the hook Choose the most suitable one of the two hooks on the strap depending on your fork diameter 5 Once mounted move the transmitter unit around to ensure the closest mounting position relative to the spoke magnet Optimum sensing distance between the magnet and the transmitter housing is 5mm Fig 3 6 A The silicon strap on the transmitter unit is has two loops and is designed to accommodate fork diameters from 20mm up to around 45mm
