Konica Minolta EP2051 [61/101] Special functions
![Konica Minolta EP2051 [61/101] Special functions](/views2/1122112/page61/bg3d.png)
*
With EXP5 at the central level, the exposure
level is lower as the number becomes smaller,
and it is higher as the number becomes greater.
Manual Exposure Mode as Default
Setting
Description
Initial Setting
10 Manual Exposure Mode / EXP1
11 Manual Exposure Mode / EXP2
12 Manual Exposure Mode / EXP3
13 Manual Exposure Mode / EXP4
14 Manual Exposure Mode / EXP5
15 Manual Exposure Mode / EXP6
16 Manual Exposure Mode / EXP7
17 Manual Exposure Mode / EXP8
18 Manual Exposure Mode / EXP9
1151H16OBA
Lighter Darker
123456789
EXP Level
1139O5282A
Determine the priority finishing mode selected when the copier is equipped with a finishing option.
Setting
Description
Initial Setting
0 Non-Sort
1 Sort
2Group
3 Sort-and-Staple
Determine the orig. copy type automatically selected when the Power Switch is turned ON o
Panel Reset key is pressed.
Setting Description Initial Setting
0 1
1 1
2 2
3 1 1 (2in1
4 1 2 (2in1
*The initial setting is 1 2 if your copier is equipped with a Duplex Unit. Consult your Technical
Representative if you want to select 1 1 when your copier is equipped a Duplex Unit
.
1151H18OBA
▼
▼
▼
▼
▼
1151H19OBA
▼
▼
U-15 Default Finishing Mode
U-18 Priority Orig. Copy Type
▼
▼
Chapter 4
Special Functions
3. User’s Choice
