D-Link DNS-346 USER’S MANUAL
Page 12 of 85
Software Setup
Easy Search Utility
When first powered on, during the initial boot sequence, the DNS-346 will wait to be assigned an IP address via DHCP. If it does not receive a DHCP assigned IP address, by
default it will have a self-assigned IP address of 192.168.0.32. It is recommended to use the included D-Link Easy Search Utility when accessing and configuring the DNS-346
for the first time. If you want to change the IP address before logging in or are unable to connect to the DNS-346 IP address, you can use the Easy Search Utility provided on the
product CD to locate the device on your network and make any needed changes.
Network Storage Device:
Refresh:
Configuration:
LAN:
Apply:
iSCSI Drive Mapping:
Connect:
Management:
Drive Mapping:
Available Drive Letters:
About:
Exit:
The Easy Search Utility displays any DNS-346 devices it detects
on the network here.
Click Refresh to refresh the device list.
Click Configuration to access the Web based configuration of the
DNS-346.
Configure the LAN Settings for the DNS-346 here. Click Apply to
save changes to the LAN Settings.
Displays the available iSCSI targets on DNS-346.
Click Connect to connect to the iSCSI target.
Click Management to edit the information.
Volumes available for mapping are displayed here.
Choose an available drive letter. Click Connect to map the
selected volume. Click Disconnect to disconnect the selected
mapped volume.
Click About to view the software version of the Easy Search Utility.
Click Exit to close the utility.
