xStack Storage Management Center Software User’s Guide 105

Table 8-1 lists the ports used by the xStack Storage. We suggest you create or revise your

source-based firewall rules/policies to accommodate outbound connections to the xStack

Storage system via these ports.

Table 8-1. xStack Storage Ports

Port Description

23 Telnet

80 http (Web Server)

443 https (Web Server)

5988 CIM

5989 CIM HTTPS

For outgoing traffic from the xStack Storage system management port, there

are no fixed port numbers (ports are ephemeral), so all ports should be open

for traffic from the xStack Storage management port. The xStack Storage

system’s iSCSI data ports only use port 3260 (standard iSCSI port).
