3. Figur 3.

Mount the two lower steer with the following bolts(c,d) Pay attention to the steer, left

and right are different.

Steer (a.) must be mounted on the right. Steer (b.) must be mounted on the left.

4. Figur 4,5.

Mount upper steer using the accompanying bolts and handwheel

Pay attention to the arrows on the plasticbrackets. They must be aligned when

mounting.

5. Figur 6, 7, 8

Mount throttlecable(a.) and clutchcables(b.) as shown on the picture.

6. Figur 9.

Fyld fedt på gearet.

a. Dismount the sparkplughcap on the engine.

b. Add grease to the transmission.

c. Place the greasebottle in a bucket with hot water. This will make the grease

thinner, and thereby easiere to fill in the the transmission.

Only cut a little of the tip on the greasebottle.

d. Fill grease on the transmission, until it runs out of the indicatorhole, when the

machine is placed in horizontal position.

e. Activate the clutchhandle and pull 3 times, this will distribute the grease in

the transmission.

f. Add more grease, until the transmission is full.

g. Mount and tighten the bolt.

h. Mount the sparkplughcap on the engine.

7. Figur 10

Mount the blades using the cotter bolts and pins.

It is important that the edge of the blade turns forward, as shown in figure 22.

8. Figur 11.

Mount the side guards using the accompanying bolts and nuts

9. Figur 12.

Mount bracket for starterhandle, as show non the picture.

Activate the clutchhandle on the right, and pull the starterhandle. Fix the line/handle

in the bracket.

10. Figur 13.

Mount debthskid with the accompanying cotterpin.

Oil and petrol

Note – Oil and petrol are not included!

Oil and petrol are not included with the machine. Fill the motor with 0.6 litres of SAE 30

motor oil and octane 92 or 95 unleaded petrol.
