Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Weight Stack Frame 1 41 Bearing Φ50.8*Φ25.4*15.9 4

2 Bottom Cross Brace 1 42 Flange 2

3 Main Frame 1 44 Yellow Grip 1

4 Seat Pad Support 1 45 Aluminium Grip Cap 2

5 Hand Bracket 1 46 Aluminium Grip Ring 2

6 Arm Bracket 1 47 Bumper Φ32*Φ25.4*40 1

7 Cam Wheel Brackets 1 48 Seat Pad 1

8 Top Cross Brace 1 49 Arm Pad 1

9 Main Bracket 1 50 Plastic Tube Guide 2

10 Adj. Handle 1 51 Spring 1

11 Pin 1 53 Big Aluminous Cap Φ60*Φ10.5*10 1

12 Main Shaft Φ25.4*335.4 1 54 Bushing 2

14 Scaleboard 1 57 Little Bumper Φ17*10.5 2

15 Adjustable Support 1 58 Bushing Φ16*8 2

16 Aluminium Cap Φ50*Φ10.5*8 2 59 Plate 2

17 Underlaying Flat Steel 1 65 Hex Head Bolt M12*35 4

18 Press Cable 1 67 Hex Head Bolt M10*135 2

19 Top Plate 1 68 Hex Head Bolt M10*130 2

20 Counter Poise Block 1 69 Hex Head Bolt M10*100 2

21 Rubber Plug Φ29*Φ19*10 2 70 Hex Head Bolt M10*80 2

24 Selector Pin W/Coil 1 71 Hex Head Bolt M10*50 2

26 Button Φ8*Φ20*23 10 72 Hex Head Bolt M10*35 2

27 Weight Rubber Bumper 2 73 Hex Head Bolt M10*30 6

28 Adjustable Foot plate 4 74 Hex Head Bolt M10*25 2

29 Grip Φ22*Φ30*355 2 75 Flat Head Cap Screw M10*30 5

34 4.5" Pulley 2 77 Socket Head Cap Screw M8*60 1

36 Plug RT50*100 1 78 Socket Head Cap Screw M8*55 1

37 Guide Rod Φ19*1177 2 79 Socket Head Cap Screw M8*30 1
