─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

80 Socket Head Cap Screw M8*20 2 116 Hex Head Bolt M8*30 2

81 Button Head Cap Screw M6*12 2 117 Spring Washer Φ8 2

82 Hex Nut M6 2 120 Rivet Nut M8 2

83 Socket Head Cap Screw M5*25 2 131 Socket Set Screw M6*15 2

85 Socket Head Cap Screw M4*15 1 132 Baffle Plate 1

86 Adjustable Support Sleeve 1 133 Hex Head Bolt M8*15 2

87 Weight Stack Space 2 141 Hex Head Bolt M10*65 2

89 Flat Washer Φ13*Φ24*1.5 11 142 Hex Head Bolt M10*55 1

90 Flat Washer Φ11*Φ20*2 36 143 Hex Head Bolt M12*70 3

91 Flat Washer Φ9*Φ16*1.6 8 144 Screw M5*12 9

92 Flat Washer Φ5.5*Φ12*1 4 145 Rivet Nut M5 5

93 Nylon lock Nut M5 2 146 Shroud clip 12

94 Nylon lock Nut M8 4 147 Plastic Cover 1

95 Nylon lock Nut M10 13 148 Plate for sensor 1

96 Nylon lock Nut M12 4 149 Philips Screw M3*8 4

97 Socket Set Screw10-32*3.2 4 150 Sensor 2

98 Hex Key s=3 1 151 Console PCB 1

99 Hex Key s=4 1 152 Screw ST2.9*9.5 2

100 Hex Key s=5 1 153 Cover for Magnetic Iron 1

101 Hex Key s=6 1 154 Magnetic Iron 2

102 Flat Washer Φ9*Φ22*1.6 2 155 Rear Shroud 1

103 Hex Key s=3/32" 1 156 Front Shroud 1

104 Wrench 1 157 Top Front Shroud 1

105 Lube 1 158 Support 1

106 Location ring 1 159 Top Cover 1

107 Locking ring 1 160 Left Plug 1

109 Socket Set Screw M8*8 4 161 Right Plug 1

110 Nut 2 162 4.5" Pulley for Sensor 1
