─ 5 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Weight Stack Frame 1 31 Plug RT50*100 3

2 Main Frame 1 32 Button Φ8*Φ20*23 8

3 Right Lat Arm 1 33 Plastic Tube Guide 2

4 Left Lat Arm 1 34 Foot Sleeve 1

5 Right Bracket 1 35 Weight Rubber Bumper Φ63.5*Φ19*25.4 2

6 Left Bracket 1 36 Plug Bumper Φ38*19.5 2

7 Assistant Bracket 1 37 Pulley Cover 4

8 Bottom Cross Brace 1 38 Stopper 2

9 Rear Cross Brace 1 39 4.5" Pulley 4

10 Seat Pad Support 1 40 3.5" Pulley 3

11 Back Pad 1 41 Plug Bumper Φ25*8 2

12 Seat Pad 1 42 Plug Bumper Φ25*15.2 1

13 Arm Pad 2 43 Top Front Shroud 1

14 Mobile Bracket 2 44 Rear Shroud 1

15 Oval Flat 1 46 Front Shroud 1

16 Spacer 2 49 Support 1

17 Aluminium Cap Φ60*Φ10.5*10.9 2 54 Adjustable Support Sleeve 1

18 Aluminium Cap Φ60*Φ10.5*10 1 56 Aluminium Grip Cap 2

19 Grip Φ30*Φ22*390 2 57 Aluminium Grip Ring 2

20 Adjustable Support 1 58 Big Washer Φ31*Φ25.5*1.5 4

21 Adjustable Foot Plate 4 59 Spring 1

22 Rod Assembly 2 60 Gas Spring 1

23 Cable1 1 61 Nut 2

24 Cable2 1 62 Bearing 6005-2Z 8

25 Selector Pin W/Coil 1 63 Bearing Φ50.8*Φ25.4*15.9 2

26 Top Plate 1 66 Hex Head Bolt M10*55 1

27 Guide Rod Φ19*1177 2 67 Hex Head Bolt M10*135 2

29 Weight Stack Space 2 68 Hex Head Bolt M10*100 2
