─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

69 Hex Head Bolt M10*75 4 98 Hex Key s=8 1

70 Hex Head Bolt M10*50 3 99 Hex Key s=10 1

71 Screw M5*12 9 100 Hex Key s=3/32" 1

72 Hex Head Bolt M10*30 12 101 Hex Key s=3/16" 1

73 Hex Head Bolt M10*25 4 102 Wrench Φ6*117 1

74 Button Head Cap Screw M8*55 1 103 Lube 1

75 Button Head Cap Screw M6*12 2 104 Weight Plate 5LBS 2

Socket Head Cap Screw M12*35

2 105 Weight Plate 10LBS 3

Socket Head Cap Screw M10*120

1 106 Weight Plate 15LBS 10

Socket Head Cap Screw M10*50

2 107 Hex Key s=4 1

79 Socket Head Cap Screw M8*30 1 109 Rubber Plug Φ29*Φ19*10 2

80 Socket Head Cap Screw M4*15 2 110 Hex Head Bolt M8*30 2

81 Flat Head Cap Screw M10*30 5 111 Spring Washer Φ8 2

82 Rivet Nut M5 5 115 Flat Washer Φ9*Φ22*1.6 2

83 Screw ST2.9*9.5 2 116 Socket Set Screw M6*15 2

84 Flat Washer Φ11*Φ20*2 44 117 Shroud clip 12

85 Flat Washer Φ9*Φ16*1.6 3 118 Plastic Cover 1

86 Flat Washer Φ11*Φ30*2 2 119 4.5" Pulley for Sensor 1

88 Nylon Lock Nut M12 2 120 Plate for sensor 1

89 Nylon Lock Nut M10 17 121 Philips Screw M3*8 4

90 Nylon Lock Nut M8 2 122 Sensor 2

91 Hex Nut M6 2 123 Console PCB 1

92 Socket Set Screw10-32*3.2 4 124 Cover for Magnetic Iron 1

93 Button Head Cap Screw M8*15 2 125 Magnetic Iron 2

94 Rivet Nut M8 2 126 Top Cover 1

95 Hex Key s=3 1 127 Left Plug 1

96 Hex Key s=5 1 128 Right Plug 1

97 Hex Key s=6 1
