─ 5 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

1 Weight Stack Frame 1 31 Connect Plate 2

2 Bottom Cross Brace 1 32 Washer Φ32*Φ26*5 2

3 Rear Frame 1 33 Nut M20*1.5*18 1

4 Connect Tube 1 34 L Bracket 2

5 Right Leg Arm 1 35 Cable Connector 1

6 Left Leg Arm 1 36 Aluminium Grip Cap 2

7 Pivot Axle Support Tube 1 37 Aluminium Grip Ring 2

8 Handle 1 38 Foot Pad 1

9 Adjustable Cam 1 39 Aluminium Cap 2

10 Cam Support Tube 1 40 Bearing 8

11 Adjustable Handle 1 41 Bushing Φ38*Φ25.4*18 2

12 Adjustable Pulley Bracket 1 42 Bushing Φ25*Φ19*20 2

13 Leg Pad Pivot Bracket 2 43 Bushing Φ25*Φ12.2*13 4

14 Pivot Actuator Plate 1 44 Bushing Φ8*Φ12*8 2

15 Pole 1 45 Nut 25*2.5*21.6 2

16 Cover 1 46 Front Shroud 1

17 Guide Rod Φ19*947 2 47 Rear Shroud 1

18 Pivot Axle Φ25*449 1 48 Shroud Retainer Plate 4

19 Pivot Axle Φ25*364 1 49 Plug 2

20 Seat Pad 1 50 Side Cover 2

21 Back Pad 1 51 Plastic Block 12

22 Leg Pad 2 52 Rubber Plug Φ29*Φ19*10 2

23 Sleeve 2 53 Connect Button Φ18*12 4

24 Pin 1 54 4.5" Pulley 5

25 Big Washer Φ55*Φ12.2*5 1 55 3.5" Pulley 2

26 Selector Pin W/Coil 1 56 Weight Rubber Bumper 2

27 Top Plate 1 57 Rubber Bumper Φ38*19.5 1

28 Cable 1 1 58 Button Φ8.1*7 12

29 Cable 2 1 59 Button Φ8*Φ20*23 19

30 Adjustable Foot Plate 3 60 Plug 1
