Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No. Part Number Description Qty

1 SL70140100 Base Frame 2

2 SL70150200 Upright Frame 1 1

3 SL70150300 Upright Frame 2 1

4 SL70100300 Weight Plate Storage 10

5 CHFPR0500 Rear Upright Frame 2

6 SL70140600 Carriage 1 1

7 CHFPR0700 Bottom Cross Frame 1

8 SL70140800 Carriage 2 1

9 CHFPR0900 Lat Bar 1

10 CHFPR1000 Lat Top Cross Brace 1

11 SL70151200 Weight Hook 1 1

12 SL70151300 Weight Hook 2 1

13 CHFPR1400 Rubber Band Rack 2

14 HVCORE3102 Flat Washer Φ57*Φ11*3 6

15 CHFPR1600 Sleeve 6

16 CHHPR1600 Long Plastic Plate 2

17 CHFPR1900 Plastic Plate 1 4

18 CHFPR2000 Plastic Plate 2 4

19 SL70100400 Weight Horn Sleeve 10

20 HF985A1500 Weight Horn Rubber Donut 10

21 RF-6012500 End Plug 10

22 BNH0573 Plug 32 2

23 GB819M6*15DHS2 Flat Head Cap Screw M6*15 38

24 GB70M10*25*25DHS20NL Socket Head Cap Screw M10*25 6

25 GB70M12*30*30DHS20NL Socket Head Cap Screw M12*30 10

26 GB70M12*100DHS20 Socket Head Cap Screw M12*100 32

27 GB70M12*105DHS20 Socket Head Cap Screw M12*105 8

28 GB9510DHS2 Flat Washer Φ11*Φ20*2 6

29 DQ12DHS2A Flat Washer Φ13*Φ24*1.5 88

30 NM12DHS2 Nylon Lock Nut M12 38

31 IF81162000 Foot Pad 4

32 IF81162300 Plastic Knob-Cap 4

33 IF81162400 Plastic Knob-Base 4

34 CNLM10*20*20DS20NL Flat Head Cap Screw M10*20 4

NBS10DHS Hex Key s=10 1

NBS8DHS Hex Key s=8 1

NBS6DHS Hex Key s=6 1
