Overall
─ 19 ─
Exploded View and Parts List
ITEM NO.
Description QTY
ITEM NO.
Description QTY
1 Left Bottom Frame Assembly 1 30 Weight Plate Storage 4
2 Right Bottom Frame Assembly 1 31 Affixed Frame 1
3 Left Union Frame Assembly 1 32 External Fixation Plate 1
4 Right Union Frame Assembly 1 33 Weight Horn Rubber Donut 2
5 Upper Beam Frame 2 34 Flat Washer Φ50.8*Φ13.5*3 2
6 Lower Beam Frame 1 35
Socket Head Cap Screw M16*100
2
7 Before Connecting Frame 1 36
Socket Head Cap Screw M12*135
22
8 Pedal Bracket 1 37
Socket Head Cap Screw M12*110
2
9 Left Foot Frame 1 38
Socket Head Cap Screw M12*85
10
10 Right Foot Frame 1 39
Socket Head Cap Screw M12*75
4
11 Foot Checkered 1 40
Socket Head Cap Screw M12*70
2
12 Arm Pad Frame Assembly 1 41
Socket Head Cap Screw M12*30
15
13 Left Handle Assembly 1 42
Socket Head Cap Screw M10*75
2
14 Right Handle Assembly 1 43
Socket Head Cap Screw M10*25
4
15
Middle Connection Frame Assembly
1 44
Socket Head Cap Screw M10*20
2
16 Link Frame Assembly 1 45 Flat Head Cap Screw M12*100 4
17
Adjustable Handle Frame Assembly
1 46 Flat Head Cap Screw M10*20 6
18 Left Extend Frame Assembly 1 47 Socket Set Screw M10*8 4
19 Right Extend Frame Assembly 1 48 Nylon Lock Nut M12 42
20 Connection Frame Assembly 1 49 Flat Washer Φ28*Φ16.5*2 2
21 Lead Rail 2 50 Flat Washer Φ13*Φ24*2.5 95
22 Weight Horn Assembly 2 51 Flat Washer Φ11*Φ20*2 6
23
Left Idler Wheel Frame Assembly
1 52 Split Lock Washer Φ12 2
24
Right Idler Wheel Frame Assembly
1 53 Hex Key S=5 1
25 Small Limit frame Assembly 1 54 Hex Key S=6 1
26 Limit Shaft Φ35 1 55 Hex Key S=8 1
27 Large Rubber Bumper 2 56 Hex Key S=10 1
28 Arm Pad 1 57 Hex Key S=12 1
29 Seat Pad 1
