Assembly

1. The Left Union Frame Assembly (#3), Right Union Frame Assembly (#4) and Left

Bottom Frame Assembly (#1), Right Bottom Frame Assembly (#2), Lead Rail (#21)

connected together using:

● two M16*100 SHCS (#35)

● four M12*85 SHCS (#38)

● two Φ28*Φ16.5*2 Flat Washers (#49)

● six Φ13*Φ24*2.5 Flat Washers (#50)

● two M12 Nylon Lock Nuts (#48)

2. The Left Union Frame Assembly (#3), Right Union Frame Assembly (#4) and Lower

Beam Frame (#6), four pieces of Weight Plate Storage (#30) connected together

using:

● eight M12*135 SHCS (#36)

● sixteen Φ13*Φ24*2.5 Flat Washers (#50)

● eight M12 Nylon Lock Nuts (#48)

Note: Hand tighten bolts and Nylon Lock nuts until machine is fully assembled.

STEP 4

The Middle Connection Frame assembly (#15) and two pieces of Upper Beam Frame

(#5) connected together, then one pieces of Upper Beam Frame (#5) and Left Union

Frame Assembly (#3), Right Union Frame Assembly (#4) connected together using:

● four M12*135 SHCS (#36)

● four M12*85 SHCS (#38)

● sixteen Φ13*Φ24*2.5 Flat Washers (#50)

● eight M12 Nylon Lock Nuts (#48)

Note: Two people will be needed to complete this step safely.

Hand tighten bolts and Nylon Lock nuts until machine is fully assembled.

STEP 3
