9
Configuring the Router (continued)
PPPoE/PPPoA Connections
If you selected the PPPoE/PPPoA connection type in the previous menu, you will see the
Setup Wizard menu pictured here. Type in the Username and Password used to identify and
verify your account to the ISP. The VPI number and VCI number should not be changed
unless you have been instructed to change them. Select the Connection Type used for
encapsulation specific to your service. Click Next when you are ready to continue to the Setup
Completed menu.
If you are not sure what Connection Type, VPI and VCI to use, please check with your ISP.
Type the
Username
and
Password
for your ISP
account.
If you have
been told to
change the
V
PI
or VCI number,
Type the new
values.
Click the Next button. Skip ahead to
the Setup Completed menu below.
Use the pull-down menu to choose the
correct Connection Type. The user may
choose between PPPoA VC-Mux, PPPoE
LLC or PPPoA LLC, as instructed by your
ISP.
