20 | English
2 610 022 197 | (9.2.12) Bosch Power Tools
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
While reading the operating instructions, unfold the graphics
page for the machine and leave it open.
Intended Use
The machine is intended for routing grooves, edges, profiles
and elongated holes as well as for copy routing in wood, plas-
tic and light building materials, while resting firmly on the
workpiece.
With reduced speed and with appropriate routing bits, non-
ferrous alloys can also be machined.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Routing motor
2 Plunge base
3 Non-plunge base
4 Handle (insulated gripping surface)
5 Adjustment knob for fine adjustment of depth-of-cut
(plunge base)
6 Scale for depth-of-cut fine adjustment
7 Release lever for plunge action
8 Index mark for fine adjustment
9 Scale for depth-of-cut adjustment (plunge base)
10 Slide with index mark (plunge base)
11 Depth stop (plunge base)
12 Turret stop
13 Base plate
14 Guide plate
15 Thumbwheel for speed preselection
16 Knurled screw for depth stop (plunge base)
17 Tightening nut with collet
18 Router bit*
19 Lock-on button for On/Off switch
20 On/Off switch
21 Securing latch for removal of motor
22 Clamping lever for plunge base/non-plunge base
23 Seat for parallel guide rods
24 Adjustment knob for depth-of-cut fine adjustment (non-
plunge base)
25 Clamping lever for depth-of-cut coarse adjustment (non-
plunge base)
26 Coarse adjustment notches for non-plunge base
27 Spindle lock button
28 Open-end spanner, size 24 mm
29 Knurled screw for extraction adapter(2x) *
30 Extraction adapter (plunge base)*
31 Extraction hose (Ø 35 mm)*
32 Extraction adapter (non-plunge base)*
33 Intermediate ring for extraction adapter (non-plunge
base)*
34 Scale for depth-of-cut adjustment
(non-plunge base)
35 Parallel guide*
36 Guide rod for parallel guide (2x)*
37 Wing bolt for fine adjustment of parallel guide (2x)*
38 Wing bolt for coarse adjustment of
parallel guide (2x)*
39 Fine-adjustment knob for parallel guide*
40 Adjustable edge guide for parallel guide *
41 Wing bolt for guide rods of parallel guide (2x)*
42 Router compass/guide-rail adapter*
43 Router compass handle*
44 Wing bolt for coarse adjustment of
router compass (2x)*
45 Wing bolt for fine adjustment of
router compass (1x)*
46 Fine-adjustment knob for router compass*
47 Centring screw for compass stop *
48 Base spacer
(included in the “router compass” set)*
49 Guide rail*
50 SDS guide-bushing adapter
51 Fastening screw for guide bushing adapter (2x)
52 Release lever for guide bushing adapter
53 Guide bushing
54 Fastening screw for guide plate
55 Centring pin
56 Fastening screws for non-plunge base*
57 Specialty Allen key for depth-of-cut fine adjustment
(non-plunge base)*
58 Extension for depth-of-cut fine adjustment
(non-plunge base)*
59 Extraction hood for edge routing *
60 Fastening screw for extraction hood *
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
