10
Step 2
Move the cursor to "SUPER-D5" and select the item from the following:
ON (default): Activates the SUPER-D5 function all the time. (+ page 10)
ON (i-VMD): Activates the SUPER-D5 function all the time. (+ page 10)
In addition to the SUPER-D5 function, the motion detection function also works.
OFF: Deactivates the SUPER-D5 function. (+ page 10)
Note:
• When"ON"or"ON(i-VMD)" is selected for "SUPER-D5", the following settings will be restricted.
SHUTTER: Only OFF and 1/120 are available. (+ page 11)
SENS UP: Only "OFF" and "AUTO" become available. (+ page 12)
• When"ON"or"ON(i-VMD)" is selected for "SUPER-D5", a shadow (black line) may appear at the boundary between a bright-
er area and a darker area. This is not a malfunction.
• When"ON"or"ON(i-VMD)" is selected for "SUPER-D5", the SUPER-D5 function will become more effective by slightly incre-
menting "LEVEL". However, flickering or noise may be observed frequently when "LEVEL" is too much incremented.
• Whenflickeringornoiseisobservedfrequentlyduetotheilluminationoflight,select"OFF".
(1) When flickering or color deterioration is observed
(2) When noise is produced in a bright area on the screen
• When"ON(i-VMD)" is selected for "SUPER-D5", performance of the motion detection will vary depending on the i-VMD set-
tings. (☞ Steps 4 - 6 on page 17)
When using the SUPER-D5 function
Follow the procedure below.
Step 1
Move the cursor to "LEVEL" and use the right or left button to adjust the level.
Step 2
The dark area of the object is automatically corrected to lighten it.
Move the cursor to "MANUAL ABS" and press the setting button.
→ The area setting screen appears.
Step 3
Move the cursor to "POSITION" and press the setting button.
Step 4
Use the up, down, right, and left buttons to determine the left upper position of the area to be set and press the setting button.
Step 5
Use the up, down, right, and left buttons to determine the right lower position of the area and press the setting button.
Note:
• Todeleteanarea,movethecursorto"DEL"andpressthesettingbutton.
• Theareatobebrighterbecomescircular.
• Thebrightlevelofanareacannotbespecified.
• Onlyoneareacanbeset.
