Back focus setting [BACK-FOCUS SETUP]

Selects the back focus setting type and performs fine adjustment. The following setting can be configured on the "BACK-

FOCUS SETUP" screen displayed from the top screen. Refer to page 5 for how to call up the screen.

The lens adjustment (☞ Installation Guide) shall be performed before the back focus adjustment.

The back focus adjustment is performed by changing the distance between the lens and focal point.

Follow the procedure below.

Important:

 • Theautobackfocusfunctionisusedforbackfocusadjustmentatinstallationandforfocuscorrectionatswitchingbetween

the color and black-and-white modes after installation. This function is not a function that is supposed to be operated contin-

uously such as the auto focus function.

 • When focus missing occurs due to secular change in the lens and installation environment or peripheral temperature

change, the back focus adjustment is required again.

Note:

 • Thebackfocusadjustmentcanbealsoperformedthroughtheoperationbuttons.(+ Refer to the Installation Guide.)

Step 1

Move the cursor to "PUSH SW" of "ABF" and press the setting button.

→ The auto back focus function provides back focus adjustment to automatically focus on a subject located in the center of the

screen.

Step 2

To fine adjust the back focus, move the cursor to "MANUAL-ADJ", press the setting button, and use the right or left button to

adjust the back focus manually.

Note:

 • Pressing the right and left buttons simultaneously for more than 2 seconds resets the back focus position to the CS mount

default position.

 • Thevalueof"INDICATOR"isaguidetoadjustthebackfocus.Thelargerthevalueis,thesharpertheimagebecomes.

"BACK-FOCUS SETUP" screen

**BACK-FOCUS SETUP**

ABF PUSH SW

MANUAL-ADJ

C/L B/W AUTO

SETUP-SW LOCK OFF

NEAR FAR

.........

INDICATOR XXXX FOCUSING

RET TOP END
