Step 3

Move the cursor to "C/L ← → B/W" and select the back focus adjustment type from the following:

AUTO (default): Adjusts the back focus function automatically and corrects out of focus when switching between color and

black-and-white images.

PRESET: Performs the preset movement to each specified back focus position when switching between color and black-and-

white images. The preset position is the back focus position specified last time, which was automatically memorized for

each of color images and black-and-white images.

FIX: Fixes the position after adjusting the back focus either automatically (ABF) or manually.

Step 4

Moving the cursor to "SETUP-SW LOCK" and selecting "ON" allow users to disable the back focus adjustment with the operation

buttons (default: OFF).

Important:

 • Thefollowingarerecommendationforbackfocussettinginaccordancewithsubjects.

 • Weshallnotresponsibleforanyinconvenience,loss,ordamagecausedbythesettingsorresultsofthebackfocusfunc-

tion.

For such case (subject conditions)

 • Normalsubject

 • Frequentlymovingsubj.

 • Subj.withremarkableilluminance

change

 • Subj.withlowilluminance

 • Toobrightorreflectivesubj.

 • Subj.throughawindow

 • Placewherethelenseasily

becomes dirty

 • Subj.withlesscontrastsuchas

white wall

 • Subj.withremarkabledepth

 • Subj.withheavyflicker

 • Subj.withhorizontallyparallellines

such as a shutter

Select this (recommendation)

Back focus adjustment

"ABF"

Fine adjustment with "MANUAL-ADJ"

after "ABF" or "MANUAL-ADJ"

"C/L ← → B/W" switching

"AUTO"

"PRESET" or "FIX"
