Panasonic WV-CP500/G [25/35] Image stabilizer setting stabilizer

Step 2

Move the cursor to the number at the right of the title and select the zone number using the right or left button.

Step 3

Move the cursor to "POSITION" and press the setting button.

Step 4

Use the up, down, right, and left buttons to determine the left upper position of the zone to be set and press the setting button.

Step 5

Use the up, down, right, and left buttons to determine the lower right position of the zone to be set and press the setting button.

→ The asterisk mark "*" will be displayed after the number and the zone setting will be saved.

Note:

 • Todeleteazone,selectthezonenumberandpressthesettingbuttonaftermovingthecursorto"DEL".

 • Tochangethesettingsofazone,selectthezonenumberandrepeatfromstep3.

13. Image stabilizer setting [STABILIZER]

Whether or not to enable the image stabilizer is determined.

This function is effective for the case that the camera is installed on a power pole or other poles.

ON: Enables the image stabilizer.

OFF (default): Disables the image stabilizer.

Important:

 • When"ON"isselectedfortheimagestabilizer,theviewanglebecomesnarrowerandtheresolutionbecomeslower.When

"ON" is selected for the image stabilizer, check the view angle and resolution at camera installation.

 • Theimagestabilizerfunctionmaynotworkforthefollowingsubjectsorconditions:

 • Darksubject

 • Lesscontrastysubject(e.g.whitewall)

 • Shortcycledimageshakingsuchasmechanicalvibration

 • Largeamplitudeimageshaking
