Panasonic WV-CP500/G [4/35] Setup menu list
![Panasonic WV-CP500/G [4/35] Setup menu list](/views2/1013958/page4/bg4.png)
4
About the setup menus
Performing each setting item in the setup menu should be completed in advance to use this unit. Perform the settings for each
item in accordance with the conditions of the camera shooting area.
The following is an example of setup procedure when LANGUAGE is set to ENGLISH.
Setup menu list
Setup item
Description
Reference
Pages
CAMERA ID This item specifies the camera title. The camera title that indicates the camera loca-
tion and other information about the camera is created with alphanumerics and sym-
bols, and is displayed on the screen.
CAMERA Performs the camera operation settings.
SCENE1/SCENE2 Selects a scene file. It is possible to register and save the settings as a scene file in
case that it is necessary to change the settings such when shooting at night or on hol-
idays.
ALC/ELC Selects the method of controlling the quantity of light in accordance with the lens to
be used.
SHUTTER Specifies the electronic shutter speed.
AGC Specifies gain adjustment.
SENS UP Specifies electronic sensitivity enhancement.
WHITE BAL Specifies white balance adjustment.
DNR Selects the level of the digital noise reduction function.
BW MODE Performs each setting regarding the black-and-white mode such as switching
between color and black-and-white images.
i-VMD Performs settings regarding intelligent VMD (Video Motion Detector) such as motion
detection and object abandonment/removal detection.
SYSTEM Performs the settings regarding the camera system such as synchronization, alarm
input/output, and privacy zone.
SYNC Specifies the synchronization type.
ALARM IN/OUT Performs the settings of the ALARM IN connector and the ALARM OUT connector.
PRIVACY ZONE Hides undesired portions in the camera shooting area.
STABILIZER Decides whether or not to enable the image stabilizer.
EL-ZOOM Toggles the electronic zoom on and off.
BACK-FOCUS Selects the back focus setting type and performs fine adjustment.
SPECIAL
CHROMA GAIN Adjusts the chroma level.
AP GAIN Adjusts the aperture level.
PEDESTAL Adjusts the pedestal (brightness) level.
PIX OFF Corrects image defects such as flaws.
COMMUNICATION Performs the communication setting of the system with a receiver into which this unit
is integrated.
CAMERA RESET Restores the settings in the setup menu to the default settings.
SER.NO. Displays the serial number of this unit.
LANGUAGE Selects a language to be used in the setup menu.
7
8
8
9
11
12
12
12
14
14
15
22
22
23
24
25
26
27
29
29
29
30
31
31
31
32
