Flaw compensation [PIX OFF]

Flaws in the displayed camera image are corrected. Up to 16 points can be corrected.

Follow the procedure below.

Step 1

Move the cursor to "PIX OFF" and press the setting button.

→ The "PIX OFF" screen appears.

Step 2

Select a number (1 to 16) with which a pixel compensation point is registered and press the setting button.

→ The pixel compensation positioning screen appears.

Step 3

Use the up, down, right, and left buttons to move the crosshair cursor to the center of the flaw to be corrected and press the set-

ting button.

→ The flaw is corrected and the pixel compensation point is registered. The "PIX OFF" screen appears again. "*" is attached at

the right side of the number when registration is completed. The coordinate is expressed in figures.

Note:

 • Tocleartheregisteredpixelcompensationpoint,movethecursortothenumberwithwhichthetargetpixelcompensation

point is registered on the "PIX OFF" screen and press the setting button. The pixel compensation positioning screen

appears, and then hold down the right and left buttons for more than 2 seconds simultaneously. The "PIX OFF" screen

appears, the pixel compensation point is cleared, and "*" at the right side of the number disappears.

**SPECIAL SETUP**

CHROMA GAIN

...

...128

AP GAIN

...

... 32

PEDESTAL

...

... 32

- +

PIX OFF

COMMUNICATION COAX

CAMERA RESET PUSH SW

SER.NO. XXXXXXXX

RET TOP END

"SPECIAL SETUP" screen "PIX OFF" screen Pixel compensation positioning screen

**PIX OFF**

1 2 3 4

5 6 7 8

9 10 11 12

13 14 15 16

000 000

RET TOP END
