Faber CYLINDRA ISOLA EG10 X A37 [10/22] Control panel

USE

Control panel

Button Led Function

Turns the lights on/off at maximum strength.

Fixed Turns the motor on/off at speed one.

Fixed Turns the Motor on at speed two.

Press and hold the button for approximately 5 seconds, with all the loads turned

off (Motor and Lights), to turn the Activated Charcoal Filter alarm on. The

relevant LED flashes twice to confirm.

To turn the alarm off, press the button again and hold for at least 5 seconds. The

relevant LED flashes once.

Fixed Turns the Motor on at speed three.

Press and hold the button for approximately 3 seconds, with all the loads turned

off (Motor and Lights), to perform a reset. The LED S1 flashes three times.

Fixed Turns the Motor on at INTENSIVE Speed.

This speed is timed to run for 10 minutes. At the end of this time, the system

returns automatically to the speed that was set before. If it is activated with the

motor turned off, the hood will switch to OFF at the end of the time.

Press and hold for 5 seconds to enable the remote control, indicated by the LED

flashing twice.

Press and hold for 5 seconds to disable the remote control, indicated by the LED

flashing just once.

Fixed Signals the Metal Grease Filter saturation alarm, indicating that it is necessary to

wash the filters. The alarm is triggered after the Hood has been in operation for

100 working hours. (Reset see the parag. Maintenance)

Flashing When this is activated, it signals the Activated Charcoal Filter saturation alarm,

indicating that the filter must be changed; the Metal Grease Filters must also be

washed. The Activated Charcoal Filter saturation alarm comes

into operation after the Hood has been working for 200 hours. (Activation and

Reset see the parag. Maintenance)

T1 T2 T3 T4
